HealthCraft’s innovative Smart-Rail makes getting out of bed easier while also providing support when sitting up or lying down. Unlike other bed assist rails, the Smart-Rail has two positions: closed and open. In the closed position (parallel to the side of the bed), the safety rail provides support for making adjustments while in bed. In the open position, the rail pivots out from the bed and touches down to the ground to assist in moving to a standing position. The Smart-Rail is also easily installed between your mattress and box spring, and secured tightly with a safety strap.





INSTALLATION

1. Insert side frames into back frame and engage spring locks.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

2. Assemble side frames to face plate with screws and lock washers.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

3. Locate frame to place pivot tube in line with your hip position when lying down. Slide support frame between box spring and mattress.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

4. Secure support frame to angle iron with supplied strap.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

5. Install pivot rail into pivot tube of face plate.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

6. Set height of rail in locked position and secure safety latch with hex key.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

7. Slide plastic bushings onto ends of pivot rail.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

8. Slide extension legs into pivot rail.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

9. Set height of pivot rail in open position, align holes and install locking pins.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

10. Ensure rail does not impact, interfere or compromise use of surroundings.

Smart Rail Instructions
Download
Bed Entrapment Prevention
Download

SPECIFICATIONS

Material Alloy steel
Finish / Colour Powder coat, white
Weight Capacity 300lbs / 136kgs
Rail Diameter 1.5" / 38.1mm
Support Arm Length 16.25” / 413mm
Height Adjustable Standard Height:
27.25"/699mm

Built-In Leg Extender Range:
2-9"/51-229mm

Total Range:
27.25/699mm to 36.25"/921mm
Grip Material Non-slip, latex free closed cell foam
Installation Mechanism Rail frame secures to bed frame
Installation Hardware/Fasteners Safety strap (Polypropylene)
Fasteners Exposed or Concealed Concealed
Commercial Use No
Residential Use Yes
Water Resistant Yes
Rust Resistant No
Country of Origin Taiwan
Shipping Dimensions Shipping Case (4 units):
29x18x15" / 737x457x381

Retail Box:
28x17x3.5"/711x432x89mm
Shipping Weight Shipping Case (4 units):
54lbs / 24.5kg

Retail Box:
13lbs/5.9kg
Warranty Limited Lifetime Warranty

Frequently Asked Questions

+ What are the height ranges when the Smart-Rail is open from the bed?

When in the open position, the rail has a height range of 27.25"/699mm to 36.25"/921mm. This allows you to set the height to what is most comfortable setting.

+ Can I put a Smart Rail on each side on my bed?

Yes, you can (as long as your bed is big enough to place both support rails between the box spring & mattress without overlapping).
